32-bit ARM Cortex-M3 microcontroller featuring 128KB Flash memory and 8KB RAM. Operates at a 24MHz CPU frequency with a 2V to 3.6V supply voltage range. Offers 80 programmable I/Os, 16 ADC channels, 2 I2C, 2 SPI, UART, USART, IrDA, and LIN interfaces. Includes 6 PWM channels, 6 timers/counters, and integrated peripherals like POR, WDT, DMA, and temperature sensor. Packaged in LQFP with dimensions of 14.2mm x 14.2mm x 1.45mm, operating from -40°C to 85°C.
Frequency24MHz
PackageLQFP
Quick Jump:
Technical Specifications
Stmicroelectronics STM32F100VBT6B technical specifications.
General
Package/Case
LQFP
Core Architecture
ARM
Data Bus Width
32b
Frequency
24MHz
Height
1.45mm
Interface
I2C, SPI, IrDA, UART, USART, LIN
Lead Free
Lead Free
Length
14.2mm
Max Frequency
24MHz
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Power Dissipation
434mW
Max Supply Voltage
3.6V
Memory Size
128KB
Memory Type
FLASH,
Min Supply Voltage
2V
Number of ADC Channels
16
Number of I/Os
80
Number of I2C Channels
2
Number of Programmable I/O
80
Number of PWM Channels
6
Number of SPI Channels
2
Number of Timers/Counters
6
Oscillator Type
Internal
Package Quantity
90
Packaging
Tray
Peripherals
POR, PWM, WDT, DMA, Temp Sensor, I2C
Radiation Hardening
No
RAM Size
8KB
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
STM32F1
Watchdog Timer
Yes
Width
14.2mm
Compliance
RoHS
Compliant
Datasheet
Stmicroelectronics STM32F100VBT6B Datasheet
Download the complete datasheet for Stmicroelectronics STM32F100VBT6B to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
