Automotive 60V, 2A SMA Low Drop Power Schottky Rectifier designed for general-purpose rectification. Features a maximum reverse voltage of 60V and an average rectified current of 2A. Operates across a wide temperature range from -40°C to 175°C, with a maximum reverse leakage current of 10mA. This surface mount component is packaged in SMA for tape and reel distribution, offering lead-free and RoHS compliance.
PackageSMA
MountingSurface Mount
Quick Jump:
Technical Specifications
Stmicroelectronics STPS2L60AY technical specifications.
General
Average Rectified Current
2A
Package/Case
SMA
Lead Free
Lead Free
Max Operating Temperature
175°C
Min Operating Temperature
-40°C
Max Reverse Leakage Current
10mA
Max Reverse Voltage (DC)
60V
Max Surge Current
75A
Mount
Surface Mount
Package Quantity
1
Packaging
Tape and Reel
RoHS Compliant
Yes
Series
Q Automotive
Compliance
RoHS
Compliant
Datasheet
Stmicroelectronics STPS2L60AY Datasheet
Download the complete datasheet for Stmicroelectronics STPS2L60AY to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
