Seven-position, male XLR audio connector for cable mounting. Features silver-plated copper alloy contacts with a 7.5A current rating and 125V AC voltage rating. Constructed with a zinc alloy shell and nickel plating, this shielded connector offers solder termination and plastic insulation.
Voltage Rating125V
Current Rating7.5A
MountingFree Hanging
Quick Jump:
Technical Specifications
Switchcraft AAA7MZ technical specifications.
General
Color
Silver
Contact Finish - Mating
SILVER
Contact Material
Copper Alloy
Contact Plating
Silver
Current Rating
7.5A
Gender
Male
Insulation Material
Plastic
Lead Free
Lead Free
Max Current Rating
5A
Mount
Free Hanging
Number of Contacts
7
Number of Ports
1
Number of Positions
7
Orientation
Vertical
Package Quantity
100
Packaging
Bulk
Plating
Nickel
RoHS Compliant
Yes
Series
Q-G® AAA
Shell Finish
Nickel
Shell Material
ZINC ALLOY
Shielding
Shielded
Termination
Solder
Voltage Rating
125V
Voltage Rating (AC)
125V
Compliance
RoHS
Compliant
Datasheet
Switchcraft AAA7MZ Datasheet
Download the complete datasheet for Switchcraft AAA7MZ to view detailed technical specifications.
No datasheet is available for this part.
