3-position male XLR connector with vertical orientation and solder termination. Features a copper alloy contact material with silver and tin plating, rated for 10A current. Constructed with a black plastic insulation and glass shell, offering a flammability rating of UL94 V-0. Designed for through-hole, panel, and flange mounting with a depth of 30mm and length of 27mm. Operates within a temperature range of -34°C to 85°C and is RoHS compliant.
Current Rating10A
MountingThrough Hole, Panel, Flanges
Quick Jump:
Technical Specifications
Switchcraft PQG3MST101 technical specifications.
General
Color
Black
Contact Finish - Mating
Electro-Tin
Contact Material
Copper Alloy
Contact Plating
Silver, Tin
Current Rating
10A
Depth
30mm
Flammability Rating
UL94 V-0
Gender
Male
Insulation Material
Plastic
Lead Free
Lead Free
Length
27mm
Max Current Rating
10A
Max Operating Temperature
85°C
Min Operating Temperature
-34°C
Mount
Through Hole, Panel, Flanges
Number of Contacts
3
Number of Ports
1
Number of Positions
3
Orientation
Vertical
Package Quantity
25
Packaging
Bulk
RoHS Compliant
Yes
Series
Q-G® PQG
Shell Material
Glass
Termination
Solder
Compliance
RoHS
Compliant
Datasheet
Switchcraft PQG3MST101 Datasheet
Download the complete datasheet for Switchcraft PQG3MST101 to view detailed technical specifications.
