CC15-2415SFH-E

15W DC-DC Converter, 15V/1A Out, 18-36V In, 1kV Isolation, Board Mount

15W DC-DC regulated power supply module, featuring a single 15V output at 1A. This hybrid, board-mount converter operates with 89% efficiency across an 18V to 36V DC input range, with a nominal input of 24V. It provides 1kV isolation and is housed in a DIP-17 package for through-hole mounting. Operating temperature range spans from -40°C to 85°C, with a maximum power dissipation of 15W.

MountingThrough Hole

Power15W

Quick Jump:

Technical Specifications

TDK CC15-2415SFH-E technical specifications.

General

Current - Output 1	1A
Depth	27.9mm
Efficiency	89%
Height	0.27inch
Isolation Voltage	1kV
Length	13.78inch
Max Input Voltage (DC)	36V
Min Input Voltage (DC)	18V
Max Input Voltage	36V
Min Input Voltage	18V
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
Max Output Current	1A
Max Output Power	15W
Max Power Dissipation	15W
Mount	Through Hole
Nominal Input Voltage	24V
Nominal Output Voltage	15V
Number of Outputs	1
Output Current	1A
Output Power	15W
Package Quantity	1
Packaging	Tray
RoHS Compliant	Yes
Series	CC-P-E
Voltage - Output 1	15V
Width	2.76inch
