Technical Specifications
TDK VS10C-12 technical specifications.
General
Current - Output 1
900mA
Depth
49mm
Efficiency
75%
Height
0.67inch
Isolation Voltage
2kV
Lead Free
Lead Free
Length
94mm
Max Operating Temperature
60°C
Min Operating Temperature
-10°C
Max Output Current
900mA
Max Output Power
10W
Max Power Dissipation
10W
Mount
Chassis Mount
Number of Outputs
1
Output Current
900mA
Output Power
10W
Output Voltage
12V
Radiation Hardening
No
RoHS Compliant
Yes
Series
VSC (10W)
Voltage - Output 1
12V
Weight
65g
Width
1.93inch
Compliance
RoHS
Compliant
Datasheet
TDK VS10C-12 Datasheet
Download the complete datasheet for TDK VS10C-12 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
