TDK VS15C-5 technical specifications.
General
Current - Output 1
3A
Depth
50mm
Efficiency
72%
Height
0.67inch
Isolation Voltage
2kV
Lead Free
Lead Free
Length
115mm
Max Operating Temperature
60°C
Min Operating Temperature
-10°C
Max Output Current
3A
Max Output Power
15W
Max Power Dissipation
15W
Mount
Chassis Mount
Number of Outputs
1
Output Current
3A
Output Power
15W
Output Voltage
5V
Radiation Hardening
No
RoHS Compliant
Yes
Series
VSC
Voltage - Output 1
5V
Weight
80g
Width
1.97inch
Compliance
RoHS
Compliant
Datasheet
TDK VS15C-5 Datasheet
Download the complete datasheet for TDK VS15C-5 to view detailed technical specifications.
