50-position, 2-row right-angle receptacle connector with 2.54mm pitch. Features female socket contacts made of gold-plated copper, rated for 1A current and 500V voltage. Designed for cable mounting with Insulation Displacement Technology (IDT) termination, supporting 26-28AWG ribbon wire. Operates within a temperature range of -55°C to 125°C, with a blue housing color.
Voltage Rating500V
Current Rating1A
MountingFree Hanging, Cable
Quick Jump:
Technical Specifications
TE Connectivity 1-1658527-5 technical specifications.
General
| Color | Blue |
| Contact Gender | Female |
| Contact Material | Copper |
| Contact Plating | Gold |
| Contact Type | Female Socket |
| Current Rating | 1A |
| Depth | 7.05mm |
| Gender | Receptacle |
| Housing Color | Blue |
| Length | 68mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Free Hanging, Cable |
| Number of Contacts | 50 |
| Number of Positions | 50 |
| Number of Rows | 2 |
| Orientation | Right Angle |
| Package Quantity | 50 |
| Packaging | Bulk |
| Pitch | 2.54mm |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | No |
| Series | 622 |
| Termination | IDT |
| Voltage Rating | 500V |
| Wire Gauge (Max) | 28AWG |
| Wire Gauge (Min) | 26AWG |
| Wire/Cable Type | Ribbon |
Compliance
| RoHS | Not Compliant |
Datasheet
TE Connectivity 1-1658527-5 Datasheet
Download the complete datasheet for TE Connectivity 1-1658527-5 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
