TE CONNECTIVITY

103653-3

Datasheet

4 Pos 2.54mm Pitch Straight Header, 3A, UL94 V-0, Thermoplastic

TE Connectivity

103653-3

Name: 103653-3 TE Connectivity
Brand: TE Connectivity
SKU: 103653-3

4 Pos 2.54mm Pitch Straight Header, 3A, UL94 V-0, Thermoplastic

4-position, 1-row male pin header with 2.54mm pitch. Features a straight, free-hanging, cable, or PCB mount orientation and a current rating of 3A. Constructed with black thermoplastic housing and bronze contacts, this connector is UL and CSA approved, UL94 V-0 flammability rated, and RoHS compliant. Includes mating alignment and mating connector lock features.

Current Rating3A

MountingFree Hanging, Cable, PCB

Quick Jump:

Technical Specifications

TE Connectivity 103653-3 technical specifications.

General

Approvals	UL, CSA
Body Material	Thermoplastic
Color	Black
Contact Current Rating	3A
Contact Gender	Male
Contact Material	Bronze
Contact Type	Male Pin
Current Rating	3A
Depth	24.13mm
ELV	Compliant
Flammability Rating	UL94 V-0
Gender	Female
Height	0.26inch
Housing Color	Black
Lead Free	Lead Free
Lead Pitch	2.54mm
Length	0.49inch
Mating Alignment	Yes (With)
Mating Connector Lock	Yes (With)
Max Operating Temperature	105°C
Min Operating Temperature	-65°C
Mount	Free Hanging, Cable, PCB
Number of Contacts	4
Number of Positions	4
Number of Rows	1
Orientation	Straight
Package Quantity	1
Packaging	Bulk
Pitch	2.54mm
Reach SVHC Compliant	No
RoHS Compliant	Yes
Row Spacing	0.1inch
Series	AMPMODU MTE
Termination	IDC
Width	6.6mm
Wire Gauge (Max)	30AWG
Wire Gauge (Min)	22AWG
Wire/Cable Gauge	30AWG
