This chip antenna is a molded, surface mount component with a 50R impedance and an operating frequency range of 1.565 to 1.585 GHz. It is lead free and compliant with ELV regulations. The antenna is available in a package quantity of 9000 units, packaged in tape and reel format. The antenna has a height of 6.05mm and a diameter of 0.63inch. It is not radiation hardened.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TE Connectivity 1513634-1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | Molded |
| Diameter | 0.63inch |
| ELV | Compliant |
| Frequency | 1.575GHz |
| Gain | 0dB |
| Height | 6.05mm |
| Impedance | 50R |
| Lead Free | Lead Free |
| Max Frequency | 1.585GHz |
| Min Frequency | 1.565GHz |
| Mount | Surface Mount |
| Number of Bands | 1 |
| Operating Frequency | 1.565 to 1.585 GHz |
| Package Quantity | 9000 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Termination | SMD/SMT |
| VSWR | 2 |
| Weight | 1g |
| RoHS | Compliant |
