200 Pos SO DIMM Socket, RA, SMD, 0.6mm Pitch, Gold Plated

TE Connectivity

1565917-4

Name: 1565917-4 TE Connectivity
Brand: TE Connectivity
SKU: 1565917-4

200 Pos SO DIMM Socket, RA, SMD, 0.6mm Pitch, Gold Plated

200-position, right-angle SO DIMM socket for DDR2 SDRAM, featuring a 0.6mm pitch and 5.2mm stack height. Designed for surface mount applications with solder termination, this black thermoplastic connector offers a 500mA contact current rating and gold-plated copper alloy contacts. Operating across a wide temperature range from -67°C to 185°C, it is RoHS and ELV compliant.

Voltage Rating1.8V

MountingSurface Mount

Quick Jump:

Technical Specifications

TE Connectivity 1565917-4 technical specifications.

General

Circuit Application	Power
Connector System	Cable-to-Board
Contact Current Rating	500mA
Contact Material	Copper Alloy
Contact Plating	Gold
ELV	Compliant
Flammability Rating	UL94 V-0
Housing Color	Black
Insulation Material	Thermoplastic
Lead Free	Lead Free
Max Operating Temperature	185°C
Memory Type	DDR2 SDRAM,
Min Operating Temperature	-67°C
Mount	Surface Mount
Number of Contacts	200
Number of Positions	200
Number of Rows	2
Orientation	Right Angle
Package Quantity	150
Packaging	Tape and Reel
PCB Mount Retention	With
Pitch	0.6mm
Radiation Hardening	No
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Row Spacing	0.244inch
Sealable	No (Without)
Stack Height	5.2mm
Termination	Solder
Voltage Rating	1.8V
