1734248-3

Datasheet

3 Pos FPC Receptacle, 1A, 125V, 0.039" Pitch, SMT

TE Connectivity

1734248-3

Name: 1734248-3 TE Connectivity
Brand: TE Connectivity
SKU: 1734248-3

Active

3 Pos FPC Receptacle, 1A, 125V, 0.039" Pitch, SMT

3-position, 1-row flex-to-board receptacle connector with a 0.039-inch pitch. Features a straight, vertical PCB mounting orientation with SMT termination and gold-plated bronze contacts rated for 1A current and 125V voltage. Includes a black nylon actuator and housing, with a shrouded design for enhanced protection. Operating temperature range is -4°C to 185°C, with UL94 V-0 flammability rating.

Voltage Rating125V

Current Rating1A

MountingSurface Mount

Quick Jump:

Pricing & Availability

Checking distributor stock and pricing after the page loads.

Chat with Datasheet

Technical Specifications

General

Actuator Color	Black
Actuator Material	Nylon, Polyamide
Connector System	Flex-to-Board
Contact Current Rating	1A
Contact Location	Bottom
Contact Material	Bronze
Contact Plating	Gold
Current Rating	1A
ELV	Compliant
Flammability Rating	UL94 V-0
Gender	Receptacle
Height	7.7mm
Housing Color	Black
Length	10.4mm
Mating Alignment	Yes (With)
Max Operating Temperature	185°C
Min Operating Temperature	-4°C
Mount	Surface Mount
Number of Contacts	3
Number of Positions	3
Number of Rows	1
Orientation	Straight
Package Quantity	1000
Packaging	Tape and Reel
PCB Mount Alignment	No (Without)
PCB Mount Retention	With
PCB Mounting Orientation	Vertical
Pitch	0.039inch
Radiation Hardening	No
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Sealable	No (Without)
Shielding	Unshielded
Shrouded	Yes (With)
Termination	SMD/SMT
Voltage Rating	125V
Width	4.6mm
Wire/Cable Type	Flat Flex
