2-position, 1-row wire-to-wire power connector with a straight orientation and 5.08mm pitch. Features a black, free-hanging receptacle housing with a UL94 V-0 flammability rating and a maximum operating temperature of 221°C. This crimp termination connector supports 16AWG wire and has a 600V AC voltage rating. It is RoHS and ELV compliant, with a depth of 22.8mm, height of 0.897 inches, and width of 0.18 inches.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TE Connectivity 175362-1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TE Connectivity 175362-1 technical specifications.
| Approvals | UL |
| Color | Black |
| Connector System | Wire-to-Wire |
| Contact Type | Female Socket |
| Depth | 22.8mm |
| ELV | Compliant |
| Flammability Rating | UL94 V-0 |
| Gender | Receptacle |
| Halogen Free | Halogen Free |
| Height | 0.897inch |
| Housing Color | Black |
| Lead Free | Lead Free |
| Length | 0.826inch |
| Max Operating Temperature | 221°C |
| Min Operating Temperature | -67°C |
| Max Voltage Rating (AC) | 600V |
| Mount | Free Hanging, Cable |
| Number of Contacts | 2 |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Orientation | Straight |
| Package Quantity | 400 |
| Packaging | Bag |
| Pitch | 5.08mm |
| Preloaded | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Sealable | No (Without) |
| Selectively Loaded | No (Without) |
| Series | Dynamic D-3500 |
| Termination | Crimp |
| VDE Tested | No |
| Voltage Rating (AC) | 600V |
| Width | 0.18inch |
| Wire/Cable Gauge | 16AWG |
| RoHS | Compliant |
