10-position, 1-row rectangular wire housing with a 2.54mm pitch, designed for straight, cable mount applications. Features male pin contacts made of bronze with a 3A current rating. Constructed from PPO and thermoplastic materials, this black housing offers mating retention and a maximum operating temperature of 105°C. Compliant with ELV and RoHS standards, it boasts a UL94 V-1 flammability rating.
Current Rating3A
MountingFree Hanging, PCB
Quick Jump:
Technical Specifications
TE Connectivity 280633 technical specifications.
General
| Color | Black |
| Contact Gender | Male |
| Contact Material | Bronze |
| Contact Type | Male Pin |
| Current Rating | 3A |
| ELV | Compliant |
| Flammability Rating | UL94 V-1 |
| Gender | Receptacle |
| Height | 0.12inch |
| Housing Color | Black |
| Lead Free | Lead Free |
| Length | 7.1mm |
| Material | PPO, Thermoplastic |
| Mating Alignment | No (Without) |
| Mating Connector Lock | No (Without) |
| Mating Retention | Yes (With) |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -65°C |
| Mount | Free Hanging, PCB |
| Number of Contacts | 10 |
| Number of Positions | 10 |
| Number of Rows | 1 |
| Orientation | Straight |
| Package Quantity | 1000 |
| Packaging | Bag |
| PCB Mount Retention | With |
| Pitch | 2.54mm |
| RoHS Compliant | Yes |
| Row Spacing | 0.1inch |
| Series | AMPMODU MOD II |
| Termination | Crimp |
Compliance
| RoHS | Compliant |
Datasheet
TE Connectivity 280633 Datasheet
Download the complete datasheet for TE Connectivity 280633 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
