281792-5

Datasheet

10 Pos 2.54mm IDC Receptacle Housing, 3A, Blue, UL94 V-0

TE Connectivity

281792-5

Name: 281792-5 TE Connectivity
Brand: TE Connectivity
SKU: 281792-5

10 Pos 2.54mm IDC Receptacle Housing, 3A, Blue, UL94 V-0

10-position, 2-row, straight receptacle wire housing with a 2.54mm pitch, designed for cable mounting. Features female socket contacts made of tin-plated bronze, rated for 3A and 500V working voltage. Constructed from glass and polyester, this blue housing offers a UL94 V-0 flammability rating and operates within a temperature range of -40°C to 105°C. Suitable for discrete wire termination with a maximum wire gauge of 28AWG.

Voltage Rating500V

Current Rating3A

MountingFree Hanging, Cable

Quick Jump:

Chat with Datasheet

Technical Specifications

TE Connectivity 281792-5 technical specifications.

General

Color	Blue
Contact Current Rating	3A
Contact Gender	Female
Contact Material	Bronze
Contact Plating	Tin
Contact Type	Female Socket
Current Rating	3A
ELV	Compliant
Flammability Rating	UL94 V-0
Gender	Receptacle
Height	5.1inch
Housing Color	Blue
Insulation Diameter	0.039inch
Lead Free	Not Applicable
Lead Pitch	2.54mm
Length	13.5mm
Material	Glass, Polyester
Mating Alignment	No (Without)
Mating Connector Lock	No (Without)
Mating Cycles	30
Mating Retention	No (Without)
Max Operating Temperature	105°C
Min Operating Temperature	-40°C
Mount	Free Hanging, Cable
Number of Contacts	10
Number of Poles	10
Number of Positions	10
Number of Rows	2
Orientation	Straight
Package Quantity	5000
Packaging	Loose Piece
PCB Mount Retention	Without
Pitch	2.54mm
RoHS Compliant	Yes
Row Spacing	0.1inch
Series	HE13/HE14
Strain Relief	No (Without)
Termination	IDC
Width	7.54mm
Wire Gauge (Max)	28AWG
Wire Gauge (Min)	26AWG
Wire/Cable Gauge	26AWG
Wire/Cable Type	Discrete
Working Voltage	500V
