PCB Mount Terminal Block, Right Angle, 2 Positions, 2 Circuits, 5.08mm Pitch. Features screwless terminal block design with interlock and side stackability. Rated for 300V AC, 17.5A, operating temperature range of -40°C to 105°C. Brass contacts with tin plating, UL94 V-0 flammability rating, and lead-free construction.
Voltage300V
Current17.5A
MountingThrough Hole
Quick Jump:
Technical Specifications
TE Connectivity 282851-2 technical specifications.
General
Closed End
No (Without)
Color
Green
Contact Material
Brass
Contact Plating
Tin
Current
17.5A
Depth
15.5mm
ELV
Compliant
Flammability Rating
UL94 V-0
Housing Color
Green
Interlock
Yes (With)
Lead Free
Lead Free
Length
10.16mm
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Max Supply Voltage (AC)
300V
Max Voltage Rating (AC)
300V
Mount
Through Hole
Number of Circuits
2
Number of Contacts
2
Number of Levels
1
Number of Positions
2
Number of Positions Per Level
2
Number of Rows
1
Orientation
Right Angle
Package Quantity
300
Packaging
Carton
Pitch
5.08mm
Plating
Brass
Radiation Hardening
No
RoHS Compliant
Yes
Screw Flange
No (Without)
Screwless Terminal Block
Yes (With)
Series
Buchanan
Side Stackable
Yes (With)
Tail Length
0.15inch
Termination
Solder
Voltage
300V
Voltage Rating (AC)
300V
Wire Gauge (Max)
30AWG
Wire Gauge (Min)
30AWG
Compliance
RoHS
Compliant
Datasheet
TE Connectivity 282851-2 Datasheet
Download the complete datasheet for TE Connectivity 282851-2 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
