High-temperature female terminal for 14-16 AWG wire, featuring a nickel body and contact material with unplated nickel plating. This non-insulated, free-hanging terminal offers a straight orientation and a crimp termination. Designed for high-temperature applications with a maximum operating temperature of 650°C, it includes a stud diameter of 5mm (M5) and a tongue thickness of 0.76mm. The terminal has an inside diameter of 2.16mm and a wire/cable diameter of 2.1mm, with a length of 16.15mm and a depth of 8.71mm.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TE Connectivity 322335 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Body Material | Nickel |
| Package/Case | 197 |
| Color | Orange, Silver |
| Contact Material | Nickel |
| Contact Plating | Unplated |
| Depth | 8.71mm |
| Features | High Temperature |
| Gender | Female |
| Government Qualified | No |
| Heavy Duty | No |
| Inside Diameter | 2.16mm |
| Insulated Wire Support | No |
| Insulation | Non-Insulated |
| Lead Free | Lead Free |
| Length | 16.15mm |
| Material | Nickel |
| Max Operating Temperature | 650°C |
| Mount | Free Hanging |
| Number of Holes | 2 |
| Orientation | Straight |
| Package Quantity | 1000 |
| Packaging | Loose Piece |
| Plating | Unplated |
| Plating Thickness | 2.54um |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Sealable | No (Without) |
| Series | STRATO-THERM |
| Stud Diameter | 5mm |
| Stud Size | M5 |
| Terminal Gender | Female |
| Termination | Crimp |
| Tongue Thickness | 0.76mm |
| Wire Gauge (Max) | 16AWG |
| Wire Gauge (Min) | 14AWG |
| Wire/Cable Diameter | 2.1mm |
| RoHS | Compliant |
