Female, insulated, straight terminal for 14-16 AWG wire. Features a copper body and contact with tin plating. Nylon insulation is blue, with a 0.17-inch insulation diameter. Rated for 300V, this crimp termination component has a 6.2mm width and 21.49mm length.
Voltage Rating300V
MountingFree Hanging
Quick Jump:
Technical Specifications
TE Connectivity 328281 technical specifications.
General
Body Material
Copper
Body Plating
Tin
Color
Blue
Contact Material
Copper
Contact Plating
Tin
Depth
6.2mm
ELV
Compliant
Gender
Female
Government Qualified
No
Heavy Duty
No
Insulated Wire Support
Yes
Insulation
Insulated
Insulation Color
Blue
Insulation Diameter
0.17inch
Insulation Material
Nylon
Lead Free
Lead Free
Length
21.49mm
Material
Copper
Mount
Free Hanging
Orientation
Straight
Package Quantity
1000
Packaging
Loose Piece
Plating
Tin
Plating Thickness
2.54um
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Sealable
No (Without)
Series
PIDG
Stud Diameter
3.68mm
Stud Size
M3.5
Terminal Material
Copper
Termination
Crimp
Tongue Thickness
0.79mm
Voltage Rating
300V
Width
6.2mm
Wire Gauge (Max)
16AWG
Wire Gauge (Min)
14AWG
Wire/Cable Diameter
0.17inch
Compliance
RoHS
Compliant
Datasheet
TE Connectivity 328281 Datasheet
Download the complete datasheet for TE Connectivity 328281 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
