Female, insulated, free-hanging terminal with a straight orientation. Features copper body with tin plating and copper/silver contacts with tin plating. Designed for crimp termination, supporting wire gauges from 16AWG to 22AWG with a maximum wire/cable diameter of 3.56mm. Offers a voltage rating of 600V AC and a maximum operating temperature of 90°C. Constructed with vinyl insulation in red, compliant with RoHS and ELV standards.
MountingFree Hanging
Quick Jump:
Technical Specifications
TE Connectivity 34145 technical specifications.
General
Body Material
Copper
Body Plating
Tin
Color
Red
Contact Material
Copper, Silver
Contact Plating
Tin
Depth
7.14mm
ELV
Compliant
Gender
Female
Government Qualified
No
Heavy Duty
No
Insulated Wire Support
Yes
Insulation
Insulated
Insulation Color
Red
Insulation Diameter
0.14inch
Insulation Material
Vinyl
Lead Free
Lead Free
Length
20.55mm
Material
Copper
Max Operating Temperature
90°C
Mount
Free Hanging
Number of Holes
1
Orientation
Straight
Package Quantity
1000
Packaging
Loose Piece
Plating
Tin
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Sealable
No (Without)
Series
Plasti-Grip
Stud Diameter
4.34mm
Stud Size
M4
Termination
Crimp
Thickness
0.79mm
Tongue Thickness
0.79mm
Voltage Rating (AC)
600V
Wire Gauge (Max)
22AWG
Wire Gauge (Min)
16AWG
Wire/Cable Diameter
3.56mm
Compliance
RoHS
Compliant
