A 15-position, 2-row, female crimp connector with a red housing and nylon material, suitable for use with 18-26AWG wire. It is compliant with ELV and RoHS regulations, and has a flammability rating of UL94 V-0. The connector is packaged in bags of 100 units and is not radiation hardened.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TE Connectivity 350523-1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TE Connectivity 350523-1 technical specifications.
| Color | Red |
| Contact Gender | Female |
| ELV | Compliant |
| Flammability Rating | UL94 V-0 |
| Housing Color | Red |
| Inside Diameter | 10.67mm |
| Lead Free | Lead Free |
| Length | 25.4mm |
| Material | Nylon |
| Number of Contacts | 15 |
| Number of Positions | 15 |
| Number of Rows | 2 |
| Number of Ways | 15 |
| Package Quantity | 100 |
| Packaging | Bag |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | MR (Miniature Rectangular) |
| Shielding | Unshielded |
| Termination | Crimp |
| Wire Gauge (Max) | 18AWG |
| Wire Gauge (Min) | 26AWG |
| RoHS | Compliant |
Download the complete datasheet for TE Connectivity 350523-1 to view detailed technical specifications.
