This 18-position, 1-row straight-through connector is made from thermoplastic with a bronze contact material and gold plating. It is compliant with ELV and RoHS regulations, and has a flammability rating of UL94 V-0. The connector is packaged in bags of 1000 units and has a pitch of 2.54mm. It is not radiation hardened and the reach SVHC compliance is unknown.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TE Connectivity 499712-1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TE Connectivity 499712-1 technical specifications.
| Approvals | CSA |
| Body Material | Thermoplastic |
| Color | Black |
| Contact Material | Bronze |
| Contact Plating | Gold |
| Depth | 1.77mm |
| ELV | Compliant |
| Flammability Rating | UL94 V-0 |
| Height | 1.77mm |
| Lead Free | Lead Free |
| Length | 5.58mm |
| Number of Positions | 18 |
| Number of Rows | 1 |
| Orientation | Straight |
| Package Quantity | 1000 |
| Packaging | Bag |
| Pitch | 2.54mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | AMP-LATCH |
| Termination | Through Hole |
| RoHS | Compliant |
