TE CONNECTIVITY

5-104362-3

Datasheet

4 Pos 2.54mm Pitch Straight Header, 3A, Gold, Thermoplastic

TE Connectivity

5-104362-3

Name: 5-104362-3 TE Connectivity
Brand: TE Connectivity
SKU: 5-104362-3

4 Pos 2.54mm Pitch Straight Header, 3A, Gold, Thermoplastic

4-position, 1-row straight male pin header for board-to-board applications. Features gold-plated brass contacts with a 3A current rating and 5.08um plating thickness. Thermoplastic housing in black, rated UL94 V-0 for flammability. Offers surface mount and through-hole mounting options with vertical PCB mounting orientation. Operating temperature range of -65°C to 105°C.

Current Rating3A

MountingSurface Mount, Through Hole

Quick Jump:

Technical Specifications

TE Connectivity 5-104362-3 technical specifications.

General

Approvals	CSA
Backwall/Post Interruptions	No (Without)
Body Material	Thermoplastic
Color	Black
Contact Current Rating	3A
Contact Finish - Mating	GOLD
Contact Gender	Male
Contact Material	Brass
Contact Mating Length	0.23inch
Contact Plating	Gold, Tin, Matte
Contact Retention	Yes (With)
Contact Shape	Square
Contact Style	Pin
Contact Type	Male Pin
Current Rating	3A
Depth	6.65mm
Flammability Rating	UL94 V-0
Height	13.59mm
Housing Color	Black
Insulation Color	Black
Insulation Material	Thermoplastic
Length	12.7mm
Mating Alignment	Yes (With)
Mating Retention	Yes (With)
Max Operating Temperature	105°C
Min Operating Temperature	-65°C
Mount	Surface Mount, Through Hole
Number of Contacts	4
Number of Positions	4
Number of Rows	1
Orientation	Straight
Package Quantity	42
Packaging	Rail/Tube
PCB Mount Alignment	No (Without)
PCB Mount Retention	With
PCB Mounting Orientation	Vertical
PCB Thickness	1.58mm
Pitch	2.54mm
Plating	Gold
Plating Thickness	5.08um
Radiation Hardening	No
Reach SVHC Compliant	No
RoHS Compliant	Yes
Row Spacing	0.1inch
Series	AMPMODU MTE
Strain Relief	No (Without)
Tail Length	3.3mm
Termination	Crimp
