The LC fiber optic connector is a multimode connector with a stainless steel body and silver plating. It is compliant with ELV and RoHS regulations. The connector has a straight orientation and a PCB termination. It operates over a frequency range of 0 to 12.4 GHz and a temperature range of -55 to 105°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TE Connectivity 504031-1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TE Connectivity 504031-1 technical specifications.
| Body Material | Stainless Steel |
| Package/Case | SIL |
| Color | Silver |
| Contact Plating | Stainless Steel |
| ELV | Compliant |
| Insertion Loss | 1.5dB |
| Lead Free | Lead Free |
| Length | 10.92mm |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -55°C |
| Mode | Multimode |
| Mount | Panel |
| Operating Frequency | 0 to 12.4 GHz |
| Orientation | Straight |
| Package Quantity | 1 |
| Packaging | Loose Piece |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Simplex/Duplex | Simplex |
| Termination | PCB |
| RoHS | Compliant |
