Signal contact for cable mounting, featuring a straight, male configuration with a crimp termination style. Constructed from brass with gold plating, this component supports a maximum current rating of 2A and is designed for wire gauges between 26AWG and 22AWG. The contact has a 1.27mm insulation diameter and a 2.66mm depth. This product is RoHS compliant and supplied in tape and reel packaging.
MountingCable
Quick Jump:
Technical Specifications
TE Connectivity 745254-2 technical specifications.
General
Circuit Application
Signal
Contact Gender
Male
Contact Material
Brass
Contact Plating
Gold
Contact Style
Crimp
Contact Type
Signal
Depth
2.66mm
Diode Type
PIN
ELV
Compliant
Gender
Male
Insulation Diameter
1.27mm
Lead Free
Lead Free
Length
14.85mm
Max Current Rating
2A
Mount
Cable
Number of Contacts
1
Number of Ports
1
Orientation
Straight
Package Quantity
10000
Packaging
Tape and Reel
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
AMPLIMITE HDP-20
Shielding
Unshielded
Termination
Crimp
Wire Gauge (Max)
22AWG
Wire Gauge (Min)
26AWG
Wire/Cable Gauge
22AWG
Compliance
RoHS
Compliant
Datasheet
TE Connectivity 745254-2 Datasheet
Download the complete datasheet for TE Connectivity 745254-2 to view detailed technical specifications.
