20-position, 2-row, straight, wire-to-wire connector housing with a 4.14mm pitch. Rated for 600V and 9.5A, this white nylon housing features a UL94 V-0 flammability rating and operates from -67°C to 221°C. Designed for free-hanging cable mounting with crimp termination, it is RoHS compliant and VDE tested.
Voltage Rating600V
Current Rating9.5A
MountingFree Hanging
Quick Jump:
Technical Specifications
TE Connectivity 794210-1 technical specifications.
General
| Approvals | UL |
| Color | Natural |
| Connector System | Wire-to-Wire |
| Contact Gender | Male |
| Contact Retention | No (Without) |
| Contact Type | Male or Female |
| Current Rating | 9.5A |
| Depth | 23.75mm |
| Flammability Rating | UL94 V-0 |
| Housing Color | White |
| Length | 47.68mm |
| Material | Nylon |
| Max Operating Temperature | 221°C |
| Min Operating Temperature | -67°C |
| Max Voltage Rating (AC) | 600V |
| Mount | Free Hanging |
| Number of Contacts | 20 |
| Number of Positions | 20 |
| Number of Rows | 2 |
| Orientation | Straight |
| Package Quantity | 100 |
| Packaging | Bag |
| Pitch | 0.162inch |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Row Spacing | 0.162mm |
| Sealable | No (Without) |
| Series | Mini-Universal MATE-N-LOK II |
| Termination | Crimp |
| VDE Tested | Yes |
| Voltage Rating | 600V |
Compliance
| RoHS | Compliant |
Datasheet
TE Connectivity 794210-1 Datasheet
Download the complete datasheet for TE Connectivity 794210-1 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
