Female quick disconnect terminal, designed for 18-22 AWG wire. Features brass body and contact with tin plating. Insulated with red nylon, accommodating an insulation diameter of 0.14 inches. Offers a 300V voltage rating and a 6.35mm mating tab width. RoHS compliant and ELV compliant.
Voltage Rating300V
MountingFree Hanging
Quick Jump:
Technical Specifications
TE Connectivity 8-640903-1 technical specifications.
General
Body Material
Brass
Body Plating
Tin
Color
Red
Contact Material
Brass
Contact Plating
Tin
Depth
7.62mm
ELV
Compliant
Gender
Female
Insulated Wire Support
Yes
Insulation
Insulated
Insulation Color
Red
Insulation Diameter
0.14inch
Insulation Material
Nylon
Lead Free
Not Applicable
Length
22.86mm
Material
Brass
Mating Tab Width
6.35mm
Mount
Free Hanging
Package Quantity
100
Packaging
Loose Piece
Plating
Tin
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
Faston, PIDG
Terminal Material
Brass
Termination
Receptacle
Voltage Rating
300V
Width
7.62mm
Wire Gauge (Max)
22AWG
Wire Gauge (Min)
18AWG
Wire/Cable Gauge
-18AWG
Compliance
RoHS
Compliant
Datasheet
TE Connectivity 8-640903-1 Datasheet
Download the complete datasheet for TE Connectivity 8-640903-1 to view detailed technical specifications.
