100-position, straight male connector accessory with a 0.025-inch pitch, designed for panel mounting. Features a polyphenylene body and bronze contacts with tin plating. Operates within a temperature range of -55°C to 105°C, with a voltage rating of 250V and UL94 V-0 flammability rating. This RoHS and ELV compliant component is supplied in a black tube packaging.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TE Connectivity 821939-1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TE Connectivity 821939-1 technical specifications.
| Body Material | Polyphenylene |
| Package/Case | PLCC |
| Color | Black |
| Contact Material | Bronze |
| Contact Plating | Tin |
| ELV | Compliant |
| Flammability Rating | UL94 V-0 |
| Gender | Male |
| Height | 4.83mm |
| Lead Free | Lead Free |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -55°C |
| Mount | Panel |
| Number of Contacts | 100 |
| Number of Positions | 100 |
| Orientation | Straight |
| Package Quantity | 38 |
| Packaging | Rail/Tube |
| Pitch | 0.025inch |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Termination | Solder |
| Voltage Rating | 250V |
| Width | 35.6mm |
| RoHS | Compliant |
