6 Position, Right Angle, Through-Hole Header for wire-to-board applications. Features brass contacts with tin plating, a 0.22-inch pitch, and 0.197-inch row spacing. This male connector has a black housing and is designed for signal applications. It includes PCB mount retention and is RoHS compliant.
MountingThrough Hole
Quick Jump:
Technical Specifications
TE Connectivity 828801-2 technical specifications.
General
Circuit Application
Signal
Color
Black
Contact Material
Brass, Tin
Contact Plating
Tin
Contact Type
Tab
Depth
25.5mm
ELV
Compliant
Gender
Male
Housing Color
Black
Length
31.1mm
Mount
Through Hole
Number of Contacts
6
Number of Positions
6
Number of Rows
2
Orientation
Right Angle
Package Quantity
588
Packaging
Bulk
PCB Mount Alignment
No (Without)
PCB Mount Retention
With
Pitch
0.22inch
Radiation Hardening
No
RoHS Compliant
Yes
Row Spacing
0.197inch
Sealable
No (Without)
Series
Junior Power Timer
Shielding
Unshielded
Tab Thickness
0.8mm
Tab Width
3mm
Termination
Solder
Width
25.9mm
Compliance
RoHS
Compliant
