The PT78604 is a 250V rated terminal block with a current rating of 6A. It is designed for PCB mount and through hole installation. The component is compliant with RoHS regulations and has a maximum operating temperature range of -40°C to 80°C. The terminal block features 15 contacts and a straight orientation. It is suitable for use in applications with a maximum voltage of 240V AC.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the TE Connectivity PT78604 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Current Rating | 6A |
| Lead Free | Lead Free |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (AC) | 240V |
| Mount | PCB, Through Hole |
| Number of Contacts | 15 |
| Orientation | Straight |
| RoHS Compliant | Yes |
| Voltage | 250V |
| Voltage Rating | 250V |
| DC Rated Voltage | 250V |
| RoHS | Compliant |
