Transparent D-type latch IC featuring 8 independent channels with 3-state outputs. This CMOS device operates from a 2V to 5.5V supply, offering 8mA output current at both high and low levels. With a propagation delay of 9.2ns, it supports surface mounting in a 20-pin SOIC package. The latch is non-inverting and operates within a temperature range of -40°C to 85°C.
PackageSOIC
MountingSurface Mount
PolarityNon-Inverting
Quick Jump:
Technical Specifications
Texas Instruments SN74AHC373DW technical specifications.
General
Package/Case
SOIC
High Level Output Current
-8mA
Independent Circuits
1
Lead Free
Lead Free
Logic Function
D-Type, Latch
Low Level Output Current
8mA
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Voltage
5.5V
Min Supply Voltage
2V
Mount
Surface Mount
Number of Bits
8
Number of Circuits
8
Number of Elements
1
Number of Input Lines
3
Number of Output Lines
1
Number of Outputs
8
Output Current
8mA
Output Type
3-STATE
Package Quantity
25
Packaging
Rail/Tube
Polarity
Non-Inverting
Propagation Delay
9.2ns
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
74AHC
Technology
CMOS
Turn-On Delay Time
1ns
Weight
0.017662oz
Compliance
RoHS
Compliant
Datasheet
Texas Instruments SN74AHC373DW Datasheet
Download the complete datasheet for Texas Instruments SN74AHC373DW to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
