PackageSIP
MountingThrough Hole
Quick Jump:
Technical Specifications
Traco Power TMR6-4810 technical specifications.
General
Package/Case
SIP
Current - Output 1
1.3A
Depth
21.8mm
Efficiency
78%
Features
SCP
Height
15.3mm
Isolation Voltage
1.6kV
Length
9.1mm
Max Input Voltage (DC)
75V
Min Input Voltage (DC)
36V
Max Input Voltage
75V
Min Input Voltage
36V
Max Operating Temperature
65°C
Min Operating Temperature
-40°C
Max Output Current
1.3A
Max Output Power
6W
Max Power Dissipation
4.3W
Mount
Through Hole
Nominal Input Voltage
48V
Number of Outputs
1
Output Current
1.3A
Output Voltage
3.3V
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
TMR 6 (6W)
Voltage - Output 1
3.3V
Weight
4.8g
Width
21.8mm
Compliance
RoHS
Compliant
Datasheet
Traco Power TMR6-4810 Datasheet
Download the complete datasheet for Traco Power TMR6-4810 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
