General purpose optocoupler featuring a phototransistor output and NPN polarity. This slotted optical switch offers a 3.18mm slot width and a 30V collector-emitter breakdown voltage. Operating within a -40°C to 100°C temperature range, it has a maximum power dissipation of 100mW and a 935nm wavelength. The component is housed in a radial, through-hole mount package with a SILICON package material.
Sign in to ask questions about the TT OPS692 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
TT OPS692 technical specifications.
| Package/Case | Radial |
| Collector Emitter Breakdown Voltage | 30V |
| Collector Emitter Saturation Voltage | 400mV |
| Collector Emitter Voltage (VCEO) | 30V |
| Collector-emitter Voltage-Max | 30V |
| Height | 5.84mm |
| Lead Free | Lead Free |
| Length | 6.22mm |
| Max Breakdown Voltage | 30V |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 100mW |
| Mount | Through Hole |
| Number of Elements | 1 |
| Output Configuration | Phototransistor |
| Output Current | 1mA |
| Output Voltage | 30V |
| Package Material | SILICON |
| Package Quantity | 50 |
| Packaging | Bulk |
| Polarity | NPN |
| Power Dissipation | 100mW |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Wavelength | 935nm |
| Width | 4.6mm |
| RoHS | Compliant |
