Bi-color Green/Red chip LED emitter, featuring a 1206 (3216) SMD/SMT package for surface mounting. Emitting green and red light with peak wavelengths of 576.5nm and 635nm respectively, this component offers a luminous intensity of 180mcd. It operates with a 20mA forward current and a 5V reverse voltage, within a temperature range of -30°C to 85°C. The diffused, semitube lens style provides a wide 130° viewing angle.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Vishay LTST-S115KRKGKT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Vishay LTST-S115KRKGKT technical specifications.
| Case Code (Imperial) | 1206 |
| Case Code (Metric) | 3216 |
| Package/Case | SMD/SMT |
| Color | Green, Red |
| Depth | 1.5mm |
| Forward Current | 20mA |
| Height | 1mm |
| Illumination Color | Green, Red |
| Lead Free | Lead Free |
| Length | 3.2mm |
| Lens Color | Colorless |
| Lens Style | Semitube, Diffused, Colorless, Rectangular |
| Lens Transparency | Clear |
| Luminous Intensity | 180mcd |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -30°C |
| Mount | Surface Mount |
| Number of Elements | 2 |
| Number of LEDs | 2 |
| Orientation | Side View |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Power Dissipation | 75mW |
| Radiation Hardening | No |
| Reverse Voltage | 5V |
| RoHS Compliant | Yes |
| Viewing Angle | 130° |
| Width | 1.6mm |
| RoHS | Compliant |
