Technical Specifications
Vishay SMBJ15CA technical specifications.
General
| Package/Case | SMB |
| Direction | Bidirectional |
| Height | 2.45mm |
| Length | 4.6mm |
| Min Breakdown Voltage | 16.7V |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Reverse Leakage Current | 1uA |
| Mount | Surface Mount |
| Peak Pulse Current | 123A |
| Peak Pulse Power | 600W |
| Reverse Standoff Voltage | 15V |
| RoHS Compliant | No |
| Width | 3.95mm |
Compliance
| RoHS | Not Compliant |
Datasheet
Vishay SMBJ15CA Datasheet
Download the complete datasheet for Vishay SMBJ15CA to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
