PackageModule
Current950uA
MountingThrough Hole
Power10mW
Quick Jump:
Technical Specifications
Vishay TSOP2436 technical specifications.
General
Package/Case
Module
Lead Length
23.6mm
Max Operating Temperature
85°C
Min Operating Temperature
-25°C
Max Supply Voltage
5.5V
Min Supply Voltage
4.5V
Mount
Through Hole
Operating Supply Current
700uA
Orientation
Side View
Output Current
5mA
Package Quantity
2160
Packaging
Rail/Tube
Power Dissipation
10mW
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Sensing Distance
45m
Supply Current
950uA
Viewing Angle
45°
Compliance
RoHS
Compliant
Datasheet
Vishay TSOP2436 Datasheet
Download the complete datasheet for Vishay TSOP2436 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
