Technical Specifications
Vishay VSMG2700-GS08 technical specifications.
General
| Package/Case | PLCC |
| Forward Current | 100mA |
| Height | 1.65mm |
| Lead Free | Lead Free |
| Length | 3mm |
| Lens Style | Circular, Round |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of LEDs | 1 |
| Orientation | Top View |
| Package Quantity | 1500 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| Reverse Voltage (DC) | 5V |
| RoHS Compliant | Yes |
| Touchscreen | Infrared (IR) |
| Viewing Angle | 120° |
| Wavelength | 830nm |
| Width | 2.8mm |
Compliance
| RoHS | Compliant |
Datasheet
Vishay VSMG2700-GS08 Datasheet
Download the complete datasheet for Vishay VSMG2700-GS08 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
