Modular terminal block featuring screw termination for wire gauges from 2AWG to 12AWG. This general-purpose terminal block offers 2 positions across 1 row and 1 deck, with a current rating of 8A and a cross-section capacity of 35mm². Constructed from UL94 V-0 rated thermoplastic insulation in a green housing, it operates within a temperature range of -50°C to 120°C. Approvals include CSA, CE, UR, NEMKO, and IEC, with RoHS compliance.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Weidmuller 1010500000 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | CSA, CE, UR, NEMKO, IEC |
| Color | Yellow |
| Flammability Rating | UL94 V-0 |
| Height | 62.5mm |
| Housing Color | Green |
| Insulation Material | Thermoplastic |
| Lead Free | Lead Free |
| Length | 56mm |
| Max Operating Temperature | 120°C |
| Min Operating Temperature | -50°C |
| Number of Circuits | 1 |
| Number of Contacts | 2 |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Number of Rows | 2 |
| Orientation | Straight |
| Package Quantity | 25 |
| Packaging | Bag |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | W |
| Terminal Width | 16mm |
| Termination | Screw |
| Weight | 82.84g |
| Width | 16mm |
| Wire Gauge (Max) | 12AWG |
| Wire Gauge (Min) | 2AWG |
| Wire/Cable Gauge | 12AWG |
| RoHS | Compliant |
