4-position, 3.5mm pitch flexible flat cable (FFC) / flexible printed circuit (FPC) connector with ZIF/LIF termination. Features a right-angle, free-hanging, cable mount orientation and screw termination. Rated for 10A current and 300V voltage, with a maximum operating temperature of 100°C and a minimum of -50°C. Constructed with a copper alloy contact material and a black housing, this connector is UL94 V-0 flammability rated and RoHS compliant.
Voltage300V
Current10A
Voltage Rating300V
Current Rating17A
Quick Jump:
Technical Specifications
Weidmuller 1615690000 technical specifications.
General
Approvals
CSA, UR
Color
Black
Contact Material
Copper Alloy
Current
10A
Current Rating
17A
Flammability Rating
UL94 V-0
Height
13mm
Housing Color
Black
Lead Free
Lead Free
Length
14mm
Max Current Rating
10A
Max Operating Temperature
100°C
Min Operating Temperature
-50°C
Mount
Free Hanging, Cable
Number of Circuits
4
Number of Contacts
4
Number of Levels
1
Number of Poles
4
Number of Positions
4
Number of Positions Per Level
4
Number of Rows
1
Orientation
Right Angle
Packaging
Box
Pitch
3.5mm
Radiation Hardening
No
Ratings
IP20
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
Omnimate BL
Termination
Screw
Voltage
300V
Voltage Rating
300V
Width
18.5mm
Wire Gauge (Max)
28AWG
Wire Gauge (Min)
14AWG
Wire/Cable Gauge
28AWG
Compliance
RoHS
Compliant
Datasheet
Weidmuller 1615690000 Datasheet
Download the complete datasheet for Weidmuller 1615690000 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
