12-position, 2-level male header for flexible flat cable (FFC) / flexible printed circuit (FPC) applications. Features a 3.5mm pitch and 10A current rating, with a 150V voltage rating. Constructed with a copper alloy contact material and tin plating, this through-hole mount connector offers a UL94 V-0 flammability rating and operates within a -50°C to 100°C temperature range. It is RoHS compliant and includes CSA and UR approvals.
Voltage150V
Current10A
Voltage Rating150V
Current Rating10A
Quick Jump:
Technical Specifications
Weidmuller 1728660000 technical specifications.
General
| Approvals | CSA, UR |
| Color | Black |
| Contact Material | Copper Alloy |
| Contact Plating | Tin |
| Current | 10A |
| Current Rating | 10A |
| Flammability Rating | UL94 V-0 |
| Gender | Male |
| Lead Free | Lead Free |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -50°C |
| Mount | Through Hole |
| Number of Contacts | 12 |
| Number of Levels | 2 |
| Number of Poles | 12 |
| Number of Positions | 12 |
| Number of Positions Per Level | 6 |
| Number of Rows | 1 |
| Packaging | Box |
| Pitch | 3.5mm |
| Radiation Hardening | No |
| Ratings | IP10 |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | Omnimate S2L |
| Termination | Solder |
| Voltage | 150V |
| Voltage Rating | 150V |
Compliance
| RoHS | Compliant |
Datasheet
Weidmuller 1728660000 Datasheet
Download the complete datasheet for Weidmuller 1728660000 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
