3-position, 3.81mm pitch, single-row, screw terminal block for cable mounting. Features a 10A current rating, 300V voltage rating, and a 17.5A current rating. Constructed with a copper alloy contact material with tin plating, and a black nylon insulator. Operates within a -50°C to 120°C temperature range, with UL94 V-0 flammability rating. IP20 rated and lead-free compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Weidmuller 1798180000 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Weidmuller 1798180000 technical specifications.
| Approvals | CSA, cURus |
| Color | Black |
| Contact Material | Copper Alloy |
| Contact Plating | Tin |
| Current | 10A |
| Current Rating | 17.5A |
| Flammability Rating | UL94 V-0 |
| Height | 12.5mm |
| Insulation Material | Nylon |
| Lead Free | Lead Free |
| Length | 21.8mm |
| Max Operating Temperature | 120°C |
| Min Operating Temperature | -50°C |
| Mount | Free Hanging |
| Number of Levels | 1 |
| Number of Poles | 3 |
| Number of Positions | 3 |
| Number of Positions Per Level | 3 |
| Number of Rows | 1 |
| Packaging | Box |
| Ratings | IP20 |
| RoHS Compliant | Yes |
| Series | Omnimate BC |
| Termination | Screw |
| Voltage | 300V |
| Voltage Rating | 300V |
| Width | 10.4mm |
| Wire Gauge (Max) | 28AWG |
| Wire Gauge (Min) | 16AWG |
| RoHS | Compliant |
