Technical Specifications
Abracon ABLS-LR-16.384MHZ-T technical specifications.
General
| ESR (Equivalent Series Resistance) | 10R |
| Frequency | 16.384MHz |
| Frequency Stability | 50ppm |
| Frequency Tolerance | 50ppm |
| Height | 4.2mm |
| Length | 11.4mm |
| Load Capacitance | 18pF |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Mount | Surface Mount |
| Package Quantity | 1000 |
| Packaging | Tape and Reel |
| RoHS Compliant | Yes |
| Series | ABLS-LR |
| Series Resistance | 10R |
| Termination | SMD/SMT |
| Tolerance | 50ppm |
| Width | 4.7mm |
Compliance
| RoHS | Compliant |
Datasheet
Abracon ABLS-LR-16.384MHZ-T Datasheet
Download the complete datasheet for Abracon ABLS-LR-16.384MHZ-T to view detailed technical specifications.
