Frequency66MHz
PackageBGA
Current15mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Adesto Technologies AT45DB642D-CU technical specifications.
General
| Access Time-Max | 6ns |
| Package/Case | BGA |
| Data Bus Width | 8b |
| Density | 64Mb |
| Frequency | 66MHz |
| Interface | SPI, Serial, Parallel |
| Max Frequency | 66MHz |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.6V |
| Memory Size | 64Mb |
| Memory Type | Non-Volatile, , FLASH, NOR |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.7V |
| Mount | Surface Mount |
| Operating Supply Voltage | 3.3V |
| Package Quantity | 378 |
| Packaging | Tray |
| RoHS Compliant | Yes |
| Supply Current | 15mA |
| Sync/Async | Asynchronous, Synchronous |
| Word Size | 8b |
Compliance
| RoHS | Compliant |
Datasheet
Adesto Technologies AT45DB642D-CU Datasheet
Download the complete datasheet for Adesto Technologies AT45DB642D-CU to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
