Alfatronix
PV3I
ALFATRONIX PV3I Non Isolated POL DC/DC Converter, PowerVerter, Fixed, Chassis, 1 Output, 36 W, 13.6 V
PackageModule
Quick Jump:
Technical Specifications
Alfatronix PV3I technical specifications.
General
Package/Case
Module
Current - Output 1
3A
Depth
88mm
Efficiency
85%
Height
50mm
Isolation Voltage
400V
Max Input Voltage (DC)
32V
Min Input Voltage (DC)
17V
Max Input Voltage
32V
Min Input Voltage
17V
Max Output Current
3A
Max Output Power
36W
Nominal Output Voltage
13.6V
Number of Outputs
1
Reach SVHC Compliant
No
Voltage - Output 1
12V
Width
87mm
Compliance
RoHS
Compliant
Datasheet
Alfatronix PV3I Datasheet
Download the complete datasheet for Alfatronix PV3I to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
