Illuminated tactile switch featuring a grey, round stem actuator with a 1.3mm length. This SPST (Single Pole Single Throw) component offers a 1.57N operating force and a 50mA current rating at 12VDC. Designed for through-hole mounting with PC pin termination, it boasts an electrical and mechanical life of 500,000 cycles. Operating within a temperature range of -20°C to 85°C, this RoHS compliant switch is supplied in bulk packaging.
Current Rating50mA
MountingThrough Hole
Quick Jump:
Technical Specifications
Alps Electric SKHHLNA010 technical specifications.
General
Actuator Color
Grey
Actuator Length
1.3mm
Actuator Type
STEM
Color
Grey
Contact Current Rating
50mA
Current Rating
50mA
Depth
7.85mm
Electrical Life
500000Cycles
Illumination Type
Illuminated
Lead Free
Lead Free
Length
7.5mm
Max Current Rating
50mA
Max Operating Temperature
85°C
Min Operating Temperature
-20°C
Max Voltage Rating (DC)
12V
Mechanical Life
500000Cycles
Mount
Through Hole
Number of Positions
2
Operating Force
1.57N
Orientation
Right Angle
Package Quantity
1000
Packaging
Bulk
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
SKHH
Termination
PC Pins
Throw Configuration
SPST
DC Rated Voltage
12V
Compliance
RoHS
Compliant
