16-bit, single-channel digital-to-analog converter (DAC) with current source and voltage output capabilities. Features SPI serial interface and a 40 kS/s conversion rate. Operates from a 10.8V to 40V supply, with a typical operating voltage of 28V. Offers bipolar and unipolar output polarity, a maximum output voltage of 20V, and a settling time of 18µs. Packaged in a 1mm high TSSOP with tin-matte contact plating.
PackageTSSOP
Current2.5mA
Power128mW
Quick Jump:
Technical Specifications
Analog Devices AD5422BREZ technical specifications.
General
Package/Case
TSSOP
Contact Plating
Tin, Matte
Conversion Rate
40KS/s
Differential Output
No
Dual Supply Voltage
28V
Height
1mm
Interface
SPI, Serial
Lead Free
Contains Lead
Length
7.8mm
Max Input Voltage
4.95V
Min Input Voltage
5.05V
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Output Voltage
20V
Min Output Voltage
5V
Max Power Dissipation
158mW
Max Supply Voltage
40V
Min Supply Voltage
10.8V
Number of Bits
16
Number of Channels
1
Number of Converters
1
Number of D/A Converters
1
Number of DAC Channels
1
Operating Supply Voltage
28V
Output Polarity
Bipolar, Unipolar
Package Quantity
62
Packaging
Rail/Tube
Power Dissipation
128mW
Radiation Hardening
No
Reach SVHC Compliant
No
Resolution
16b
RoHS Compliant
Yes
Sampling Rate
40KS/s
Settling Time
18us
Slew Rate
0.8V/µs
Supply Current
2.5mA
Width
4.4mm
Compliance
RoHS
Compliant
Datasheet
Analog Devices AD5422BREZ Datasheet
Download the complete datasheet for Analog Devices AD5422BREZ to view detailed technical specifications.
