The AD5625RBRUZ-2REEL7 is a 12-bit voltage digital-to-analog converter (DAC) with a conversion rate of 333 kilo-samples per second. It operates over a temperature range of -40°C to 105°C and has a maximum power dissipation of 11.8 milliwatts. The device is packaged in a lead-free TSSOP-14 package and is RoHS compliant. It features an integral nonlinearity of 1 least significant bit and a settling time of 3 microseconds.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Analog Devices AD5625RBRUZ-2REEL7 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Analog Devices AD5625RBRUZ-2REEL7 technical specifications.
| Package/Case | TSSOP |
| Conversion Rate | 333KS/s |
| Integral Nonlinearity (INL) | 1LSB |
| Lead Free | Contains Lead |
| Max Input Voltage | 5.5V |
| Min Input Voltage | 750mV |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Max Output Voltage | 5.5V |
| Min Output Voltage | 750mV |
| Number of Bits | 12 |
| Output Type | Voltage |
| Packaging | Tape and Reel |
| Power Dissipation | 11.8mW |
| Resolution | 12b |
| RoHS Compliant | Yes |
| Sampling Rate | 333KS/s |
| Settling Time | 3us |
| Slew Rate | 1.8V/µs |
| RoHS | Compliant |
