AD589SH

1.235V Shunt Voltage Reference IC, 5mA Output, TO-51

Two-terminal IC voltage reference offering a fixed 1.235V output with a tight tolerance of 1.22%. This shunt reference operates with a nominal supply current of 50µA and supports an output current of up to 5mA. Designed for through-hole mounting in a TO-51 package, it functions across a wide temperature range from -55°C to 125°C.

PackageTO-51

MountingThrough Hole

Quick Jump:

Technical Specifications

Analog Devices AD589SH technical specifications.

General

Package/Case	TO-51
Cathode Current	50uA
Height	1mm
Lead Free	Contains Lead
Length	7mm
Max Input Current	5mA
Max Operating Temperature	125°C
Min Operating Temperature	-55°C
Max Output Current	5mA
Max Output Voltage	1.235V
Min Output Voltage	1.235V
Mount	Through Hole
Nominal Supply Current	50uA
Operating Supply Current	50uA
Output Current	5mA
Output Type	Fixed
Output Voltage	1.235V
Package Quantity	100
Packaging	Bulk
Radiation Hardening	No
Reach SVHC Compliant	No
Reference Type	Shunt
Reference Voltage	1.235V
RoHS Compliant	Yes
Tolerance	1.22%
Width	7mm
