Instrumentation amplifier featuring integrated cold junction compensation for Type J thermocouples. Offers a 15kHz bandwidth and a gain bandwidth product of 15kHz. Operates from a dual supply voltage of ±15V or a single supply of 4.5V to 5.5V, with a typical operating supply current of 300µA. This single-channel analog output amplifier is housed in a Q package with through-hole termination and tin/lead contact plating, suitable for operation between -55°C and 125°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Analog Devices AD594AQ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Bandwidth | 15kHz |
| Package/Case | Q |
| Contact Plating | Tin, Lead |
| Dual Supply Voltage | 15V |
| Gain Bandwidth Product | 15kHz |
| Height | 3.76mm |
| Interface | Analog |
| Lead Free | Contains Lead |
| Length | 19.55mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 4.5V |
| Number of Amplifiers | 1 |
| Operating Supply Current | 300uA |
| Operating Supply Voltage | 5V |
| Output | ANALOG |
| Output Current | 5mA |
| Output Type | Analog |
| Output Voltage | 13V |
| Package Quantity | 25 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | No |
| Supply Current | 300uA |
| Termination | Through Hole |
| Width | 6.6mm |
| RoHS | Not CompliantNo |
