Surface mount up/down conversion mixer operating at 500MHz. Features a 3V nominal supply voltage, with a range of 2.92V to 5.5V. This integrated circuit offers a wide frequency range from 400kHz to 12MHz. Housed in a 20-pin SSOP package with tin, matte contact plating, it operates between -40°C and 85°C. Maximum power dissipation is 600mW.
Frequency500MHz
PackageSSOP
MountingSurface Mount
Power600mW
Quick Jump:
Technical Specifications
Analog Devices AD607ARSZ technical specifications.
General
| Package/Case | SSOP |
| Contact Plating | Tin, Matte |
| Frequency | 500MHz |
| Height | 1.75mm |
| Lead Free | Contains Lead |
| Length | 7.2mm |
| Logic Function | Receiver |
| Max Frequency | 12MHz |
| Min Frequency | 400kHz |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 600mW |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 2.92V |
| Mount | Surface Mount |
| Nominal Supply Current | 8.5mA |
| Operating Supply Voltage | 3V |
| Package Quantity | 66 |
| Packaging | Rail/Tube |
| Power Dissipation | 600mW |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Width | 5.3mm |
Compliance
| RoHS | Compliant |
Datasheet
Analog Devices AD607ARSZ Datasheet
Download the complete datasheet for Analog Devices AD607ARSZ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
