RMS to DC converter IC featuring a 190kHz bandwidth and 170kHz -3dB bandwidth. This component operates with a supply voltage range of 2.8V to 16.5V, drawing 160uA of supply current. It offers a maximum input voltage of 1V and a maximum output current of 160uA. Housed in an 8-pin PDIP package with tin, matte contact plating, this through-hole and surface mountable device has a maximum power dissipation of 200mW and an operating temperature range of 0°C to 70°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Analog Devices AD737JNZ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Analog Devices AD737JNZ technical specifications.
| -3db Bandwidth | 170kHz |
| Bandwidth | 190kHz |
| Package/Case | PDIP |
| Contact Plating | Tin, Matte |
| Height | 3.3mm |
| Input Current | 160uA |
| Lead Free | Contains Lead |
| Length | 9.27mm |
| Max Input Voltage | 1V |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Output Current | 160uA |
| Max Power Dissipation | 200mW |
| Max Supply Voltage | 16.5V |
| Min Supply Voltage | 2.8V |
| Mount | Through Hole, Surface Mount |
| Operating Supply Current | 160uA |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Power Dissipation | 200mW |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Supply Current | 160uA |
| Width | 6.35mm |
| RoHS | Compliant |
